Backhoe








Specifications
Backhoe
Uses:
- To clean up constructions areas by moving large piles of dirt from one place to another regardless of terrain
- To dig the ground
- To smooth out uneven terrain with the use of the digging bucket
- To create trenches
- To carve ditches or dikes
- To remove deep-seated roots of trees
Features:
- Suits all types of tractors with Cat 1 or 2, 3-point linkage kit;
- Joystick style control console;
- Tough and reliable hydraulic arm;
- Individually controlled support legs;
- Boom lockout pins for transport
TOWNSUNNY Backhoe Specifications | |||
MODEL | BK-6N | BK-7.5N | BK-215 |
DIGGING DEPTH | 73.9"(1877mm) | 90.2"(2219mm) | 86.6"(2200mm) |
SWING ANGLE | 180º | 180º | 180º |
LOADING HEIGHT | 65.0"(1651mm) | 75.5"(1918mm) | 72.8"(1850mm) |
REACH-from centerline SWING PIVOT | 98.1"(2492mm) | 116.5"(2959mm) | 126"(3200mm) |
TRANSPORT HEIGHT | 70.7"(1796mm) | 79.8"(2027mm) | 83.8"(2120mm) |
BUCKET ROTATION | 180º | 180º | 180º |
STABILIZER SPREAD-FULL UP | 59.0"(1498mm) | 59.0"(1498mm) | 46.5"(1180mm) |
SHIPPING WEIGHT | 396kg | 425kg | 450kg |
