Rotary Tillers(1GL)
| Model | 1GL105 | 1GL125 | 1GL135 | 1GL150 | 1GL165 | 1GL180 | |||||
| Dimentions(LxWxH mm) | 127X76X107 | 152X76X107 | 152X76X107 | 175X76X107 | 187X76X107 | 202*76*107 | |||||
| Weight(kg) | 300 | 320 | 320 | 340 | 350 | 360 | |||||
| Working width(mm) | 105 | 130 | 130 | 155 | 155 | 180 | |||||
| Number of flanges | 4 | 5 | 5 | 6 | 6 | 7 | |||||
| Number of blades per flange | 6 | ||||||||||
| Hitch type | standard 3-point hitch | ||||||||||
| Gearbox lubrication | SAE 90 oil | ||||||||||
| Rotor diameter | 18'' | ||||||||||
| Rotor shaft speed | 214 rpm at 540 rpm PTO | ||||||||||
| Recommended maximum PTO power(kw) | 18.4-22.1 | 22.1-29.4 | 36.8-44.1 | ||||||||
| Dimentions(LxWxH mm) | 127X76X81 | 152X76X81 | 152X76X81 | 175X76X81 | 187X76X81 | 205X76X81 | |||||
| POWER REQUIRED | 25-30hp | 35-45hp | 40-50hp | 50-65hp | |||||||
